Epson EB-680 - Page 18

Projector Parts and Functions
18
Name Function
A
Power button [ ]
Turns the projector on or off.
From now on, referred to as the power button.
B
[Computer] button Switches the image source between the Computer1 and
Computer2 ports.
C
[HDMI/Video]
button
Switches the image source between the HDMI and
Video ports.
D
Numeric buttons Enters numbers in the projector's menu while holding
down the [Num] button.
E
[Auto] button Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from the Computer port.
F
[Aspect] button Changes the aspect mode.
G
[Num] button Hold down this button to enter numbers using the
numeric buttons.
H
[Menu] button Displays and closes the projector's menu.
I
Arrow buttons Selects menu items while displaying the projector's
menu or help.
J
[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu or help.
Acts as a mouse's left button when using the Wireless
Mouse function.
From now on, referred to as the [Enter] button.
K
[User] button Performs settings assigned in the User Button setting
in the projector's Settings menu.
L
[Page] up/down
buttons
Controls page up and down on your computer when
you connect a projector and computer using a USB
cable or over a network.
Displays the previous or next screen while using the PC
Free feature.
M
[E-Zoom] +/–
buttons
Zooms in or zooms out the image area.
N
[A/V Mute] button Turns the video and audio on or off temporarily.
Name Function
O
[Split] button Projects two images from different image sources
simultaneously by splitting the projected screen.
P
Strap attachment
point
Allows you to attach a commercially available strap to
the remote control.
Q
[Home] button Displays and closes the Home screen.
R
[Freeze] button Pauses or resumes images.
S
[Volume] up/down
buttons
Adjusts the speaker volume.
T
[Pointer] button Displays the on-screen pointer.
U
[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
Acts as a mouse's right button when using the Wireless
Mouse function.
V
[Pen Mode] button Changes between operating the computer or drawing
using the interactive pen.
W
[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
using the remote control.
X
[Color Mode] button Changes the color mode.
Y
[Link Menu] button Displays the settings menu for the device linked to the
projector's HDMI ports.
Z
[LAN] button Switches the image source between the network
connected devices.
a
[USB] button
Switches the image source between the USB Display
and USB-A port.
b
[Source Search]
button
Changes to the next input source.
c
Remote control light
emitting area
Outputs remote control signals.
