Remote Control
Name Function
A
[ ] button
Turns the projector on.
B
[t] button
Turns the projector off.
C
Change input buttons
Changes to images from each input port.
s "Switching to the Target Image by Remote Control"
p.50
The [SDI] button is not available for this projector.
D
[Auto] button
If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E
[Aspect] button
Each time the button is pressed, the aspect mode changes.
s "Changing the Aspect Ratio of the Projected Image "
p.57
F
[Test Pattern] button
Displays a test pattern.
s "Displaying a Test Pattern" p.29
G
[Freeze] button
Images are paused or unpaused.
s "Freezing the Image (Freeze)" p.75
H
[Menu] button
Displays and closes the Configuration menu.
s "Using the Configuration Menu" p.89
I
[ ][ ][ ][ ]
buttons
• When the Configuration menu or the Help screen is
displayed, pressing these buttons selects menu items
and setting values.
s "Using the Configuration Menu" p.89
• When using the optional wireless mouse receiver,
pressing these buttons moves the pointer.
s "Optional Accessories" p.172
J
[ ] button
• When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
s "Using the Configuration Menu" p.89
• Acts as a mouse's left button when using the optional
wireless mouse receiver.
s "Optional Accessories" p.172
Part Names and Functions
18
