Name Function
C
[ ]/[ ] buttons
• Displays the Control Panel Lock screen allowing you to
make settings to lock the control panel buttons.
s
"Restricting Operation" p.85
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Using the Configuration Menu" p.89
s "Using the Help" p.121
D
[ ] button
• When the Configuration menu or the Help screen is
displayed, it accepts and enters the current selection and
moves to the next level.
• If pressed while projecting analog RGB signals from the
Computer port or the BNC port, you can automatically
optimize Tracking, Sync., and Position.
E
[ ]/[ ] buttons
• Displays a test pattern.
s "Displaying a Test Pattern" p.29
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Using the Configuration Menu" p.89
s "Using the Help" p.121
F
[ ]/[ ] buttons
• Displays the Info menu from the Configuration menu.
s "Info Menu (Display Only)" p.113
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Using the Configuration Menu" p.89
s "Using the Help" p.121
G
[A/V Mute] button
Turns the video and audio on or off.
s "Hiding the Image and Sound Temporarily (A/V
Mute)" p.74
Name Function
H
[Esc] button
• Stops the current function.
• If pressed when the Configuration menu is displayed, it
moves to the previous menu level.
s "Using the Configuration Menu" p.89
I
[ ]/[ ] buttons
• Performs screen adjustments using the settings in
Geometric Correction from the Configuration menu.
s Settings - Geometric Correction p.95
• If pressed when the Configuration menu or the Help
screen is displayed, this button selects menu items and
setting values.
s "Using the Configuration Menu" p.89
s "Using the Help" p.121
J
[Menu] button
Displays and closes the Configuration menu.
s "Using the Configuration Menu" p.89
Part Names and Functions
17
