Image Quality Settings - Image Menu
101
Settings on the Image menu let you adjust the quality of your image for the
input source you are currently using. The available settings depend on the
currently selected input source.
To change settings for an input source, make sure the source is connected and
select that source.
Setting Options Description
Color Mode See the list of
available color
modes
Adjusts the vividness of image colors for
various image types and environments.
Brightness Varying levels
available
Lightens or darkens the overall image.
Contrast Varying levels
available
Adjusts the difference between light and
dark areas of the image.
Color Saturation Varying levels
available
Adjusts the intensity of the image colors.
Tint Varying levels
available
Adjusts the balance of green to magenta
tones in the image.
Sharpness Varying levels
available
Adjusts the sharpness or softness of
image details.
Setting Options Description
Color Temp. Sets the color tone based on color
temperature. The image is tinted blue
when a high value is selected and tinted
red when a low value is selected.
Color Temp. Color Temp.: sets the color temperature
according to the color mode you selected.
Customized Customized: adjusts the individual R
(red), G (green), and B (blue)
components of the offset and gain.
Enhancement
Noise Reduction Reduces flickering in analog images.
Advanced Selects the various detailed color settings:
Deinterlacing
(For interlaced
signal
[480i/576i/1080i]
input)
Deinterlacing: sets whether or not to
convert interlaced-to-progressive signals
for certain video image types.
Off: for fast-moving video images.
Video: for most video images.
Film/Auto: for movies, computer
graphics, and animation.
Auto Iris Off
Normal
High Speed
Adjusts the projected luminance based
on the image brightness.
Available when the Color Mode is set to
Dynamic or Cinema.
Reset Resets all adjustment values on the
Image menu for the selected color mode
to their default settings.
a
The Brightness setting does not affect lamp brightness. To change
the lamp brightness mode, use the Power Consumption setting in
the projector's ECO menu.
gg Related Links
"Available Color Modes" p.50
