Name Function
D
Security slot
The Security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s "Anti-Theft Lock" p.61
E
Lamp Cover Fixing
Screw
Screw to fix the lamp cover in place.
F
HDMI port (EB-X14/
EB-W12/EB-X12 only)
Inputs video signals from HDMI compatible video
equipment and computers. This projector is
compatible with
HDCP
g
.
s "Connecting Equipment" p.23
G
Computer port
Inputs image signals from a computer and component
video signals from other video sources.
H
USB(TypeB) port
• Connects the projector to a computer via the USB
cable, and the image on the computer is projected.
s
"Projecting with USB Display" p.32
• Also use this port to connect to a computer via the
USB cable to use the Wireless Mouse function.
s "Using the Remote Control to Operate the
Mouse Pointer (Wireless Mouse)" p.55
I
USB(TypeA) port
• Connects a USB memory device or a digital camera,
and projects images as a Slideshow.
s "Projecting Without a Computer (Slideshow)"
p.47
• Connects the optional Document Camera.
J
S-Video port
For S-video signals from video sources.
K
Audio-L/R port
Inputs audio from equipment connected to the
Computer port, the S-Video port, or the Video port.
L
Monitor Out port
*
(EB-S12/EB-X11/EB-
S11 only)
Outputs analog RGB signals input from the Computer
port to an external monitor. You cannot output
signals input from other ports or component video
signals.
Name Function
M
Audio Output port
*
(EB-S12/EB-X11/EB-
S11 only)
Outputs the sound of the image currently being
projected to external speakers.
N
RS-232C port
(EB-X11/EB-S11 only)
When controlling the projector from a computer,
connect it to the computer with an RS-232C cable.
This port is for control use and should not normally
be used.
s "ESC/VP21 Commands" p.62
*
Depending on the area of purchase, the Monitor Out port and the Audio
Output port may not be available for EB-S12.
Part Names and Functions
12
