Epson EB-W49 User Manual

Contents
2
Notations Used in This Guide 7
Using the Manual to Search for Information .................................. 8
Searching by Keyword................................................................................................................... 8
Jumping Directly from Bookmarks............................................................................................ 8
Printing Only the Pages You Need............................................................................................ 8
Getting the Latest Version of the Documents................................. 9
List of Functions 10
Introduction to Your Projector 14
Projector Features............................................................................ 15
Quick and Easy Setup .................................................................................................................. 15
Easy Wireless Projection ............................................................................................................. 15
Projector Parts and Functions ........................................................ 17
Projector Parts - Front.................................................................................................................. 17
Projector Parts - Rear.................................................................................................................... 18
Projector Parts - Base ................................................................................................................... 19
Projector Parts - Control Panel................................................................................................. 20
Projector Parts - Remote Control ............................................................................................ 21
Setting Up the Projector 23
Projector Placement ........................................................................ 24
Projector Setup and Installation Options............................................................................. 25
Projection Distance....................................................................................................................... 25
Projector Connections ..................................................................... 27
Connecting to a Computer........................................................................................................ 27
Connecting to a Computer for VGA Video and Audio.............................................. 27
Connecting to a Computer for USB Video and Audio............................................... 28
Connecting to a Computer for HDMI Video and Audio ........................................... 29
Connecting to Video Sources ................................................................................................... 29
Connecting to an HDMI Video Source ............................................................................ 30
Connecting to a Composite Video Source..................................................................... 30
Connecting to External USB Devices ..................................................................................... 31
USB Device Projection ........................................................................................................... 31
Connecting to a USB Device ............................................................................................... 31
Disconnecting a USB Device ............................................................................................... 32
Connecting to a Document Camera ...................................................................................... 32
Connecting to External Devices............................................................................................... 32
Connecting to a VGA Monitor ............................................................................................ 32
Connecting to External Speakers ...................................................................................... 33
Connecting a Microphone ................................................................................................... 34
Installing Batteries in the Remote Control.................................... 35
Remote Control Operation.............................................................. 36
Opening the Lens Cover .................................................................. 37
Using Basic Projector Features 38
Turning On the Projector ................................................................ 39
Home Screen................................................................................................................................... 40
Turning Off the Projector ................................................................ 42
Setting the Date and Time .............................................................. 43
Selecting the Language for the Projector Menus ......................... 45
Projection Modes ............................................................................. 46
Changing the Projection Mode Using the Remote Control.......................................... 46
Changing the Projection Mode Using the Menus ............................................................ 46
Displaying a Test Pattern ................................................................ 48
Adjusting the Image Height............................................................ 49
Image Shape..................................................................................... 50
Auto V-Keystone ............................................................................................................................ 50
Correcting the Image Shape with the Horizontal Keystone Slider............................. 50

Epson EB-W49 Specifications

General

Matrix size	0.59 \
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	- m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	33 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2600 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	8000 h
Service life of light source (economic mode)	17000 h
Focus	Manual
Throw ratio	1.30 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Full HD	No
Video processing	10 bit
Video color modes	Dynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system	-
Composite video in	1
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Noise level	37 dB
Preset modes	Blackboard, Dynamic, Presentation, Theatre, sRGB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	5 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Network Projection, Epson Projektor Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Harmonized System (HS) code	85286200
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	249 mm
Width	302 mm
Height	87 mm
Weight	2700 g
Package depth	380 mm
Package width	350 mm
Package height	160 mm
Package weight	4010 g
