Epson EB-W49 User Manual

Saving a User's Logo Image
77
You can save an image on the projector and display it whenever the projector
turns on. You can also display the image when the projector is not receiving
an input signal. This image is called the user's logo screen.
You can select a photo, graphic, or company logo as the user's logo, which is
useful in identifying the projector's owner to help deter theft. You can prevent
changes to the user's logo by setting up password protection.
a
• If the User's Logo Protection setting in the Password Protection
setting menu is set to On, set to Off before saving the user's logo.
• When you copy the menu settings from one projector to another
using the batch setup feature, user's logo is also copied. Do not
register the information that you do not want to share between
multiple projectors as a user's logo.
• You cannot save content that is protected by HDCP.
a
Display the image you want to project as the user's logo.
b
Press the [Menu] button, select the Extended menu, and press [Enter].
c
Select User's Logo > Start Setting and press [Enter].
You see a prompt asking if you want to use the displayed image as a
user's logo.
a
Adjustments such as Keystone, E-Zoom, or Aspect are
temporarily canceled when you select User's Logo.
d
Select Yes and press [Enter].
e
Check the displayed image, and then select Yes to save it as the user's
logo.
The user's logo is overwritten and a completion message is displayed.
f
Press [Esc] to exit the message screen.
g
Select the Extended menu and press [Enter].
h
Select Display and press [Enter].
i
Select when you want to display the User's Logo screen:
• To display it whenever there is no input signal, select Display
Background and set it to Logo.
s Extended > Display > Display Background
• To display it whenever you turn the projector on, select Startup
Screen and set it to On.
s Extended > Display > Startup Screen
• To display it whenever you press the [A/V Mute] button, select A/V
Mute and set it to Logo.
s Extended > Display > A/V Mute
To prevent anyone from changing the User's Logo settings without first
entering a password, set the User's Logo Protection setting to On in the
Password Protection setting menu and set the password.
gg Related Links
• "Shutting Off the Image and Sound Temporarily" p.73
• "Selecting Password Security Types" p.83

Epson EB-W49 Specifications

General

Matrix size	0.59 \
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	- m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	33 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2600 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	8000 h
Service life of light source (economic mode)	17000 h
Focus	Manual
Throw ratio	1.30 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Full HD	No
Video processing	10 bit
Video color modes	Dynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system	-
Composite video in	1
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Noise level	37 dB
Preset modes	Blackboard, Dynamic, Presentation, Theatre, sRGB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	5 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Network Projection, Epson Projektor Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Harmonized System (HS) code	85286200
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	249 mm
Width	302 mm
Height	87 mm
Weight	2700 g
Package depth	380 mm
Package width	350 mm
Package height	160 mm
Package weight	4010 g
