Epson EB-W49 User Manual

Projector Parts and Functions
22
Name Function
A
Power button [ ]
Turns the projector on or off.
B
[HDMI] button Switches the image source between the HDMI ports.
C
[Computer] button Switches the image source to the Computer ports.
D
Numeric buttons Enters numbers in the projector's menu while holding
down the [Num] button.
E
[Auto] button Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from the Computer ports.
F
[Num] button Hold down this button to enter numbers using the
numeric buttons.
G
[Menu] button Displays and closes the projector's menu.
H
Arrow buttons Selects menu items while displaying the projector's
menu.
I
[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu.
J
[User] button Performs settings assigned in the User Button setting
in the projector's Settings menu.
K
[Color Mode] button Changes the color mode.
L
[Aspect] button Changes the aspect mode.
M
[E-Zoom] +/–
buttons
Resizes the projected image.
N
[A/V Mute] button Turns the video and audio on or off temporarily.
O
[Split] button Projects two images from different image sources
simultaneously by splitting the projected screen.
P
[Home] button Displays and closes the Home screen.
Q
[Freeze] button Pauses or resumes images.
R
[Volume] up/down
buttons
Adjusts the speaker volume.
S
[Default] button Returns the selected setting to its default value.
Name Function
T
[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
U
[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
using the remote control.
V
[LAN] button Switches the image source between the network
connected devices.
W
[USB] button Switches the image source between the USB Display
and USB-A port.
X
[Source Search]
button
Switches to the next input source.
Y
Remote control light
emitting area
Outputs remote control signals.
gg Related Links
• "Image Aspect Ratio" p.58
• "Adjusting Image Quality (Color Mode)" p.61
• "Input Signal Settings - Signal Menu" p.131
• "Projector Setup Settings - Extended Menu" p.134
• "Home Screen" p.40
• "Projecting Two Images Simultaneously" p.65
• "Connecting to a Computer for USB Video and Audio" p.28
• "Projecting a PC Free Presentation" p.68
• "Using the Projector on a Network" p.87

Epson EB-W49 Specifications

General

Matrix size	0.59 \
Number of colors	1.07 billion colors
Native aspect ratio	16:10
Projection distance	- m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	33 - 320 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2600 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	8000 h
Service life of light source (economic mode)	17000 h
Focus	Manual
Throw ratio	1.30 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Full HD	No
Video processing	10 bit
Video color modes	Dynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system	-
Composite video in	1
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Noise level	37 dB
Preset modes	Blackboard, Dynamic, Presentation, Theatre, sRGB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	5 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Network Projection, Epson Projektor Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Harmonized System (HS) code	85286200
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	249 mm
Width	302 mm
Height	87 mm
Weight	2700 g
Package depth	380 mm
Package width	350 mm
Package height	160 mm
Package weight	4010 g
