Epson EB-X14 User Manual

Name Function
D
Security slot
The Security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s "Anti-Theft Lock" p.61
E
Lamp Cover Fixing
Screw
Screw to fix the lamp cover in place.
F
HDMI port (EB-X14/
EB-W12/EB-X12 only)
Inputs video signals from HDMI compatible video
equipment and computers. This projector is
compatible with
HDCP g .
s "Connecting Equipment" p.23
G
Computer port
Inputs image signals from a computer and component
video signals from other video sources.
H
USB(TypeB) port
• Connects the projector to a computer via the USB
cable, and the image on the computer is projected.
s
"Projecting with USB Display" p.32
• Also use this port to connect to a computer via the
USB cable to use the Wireless Mouse function.
s "Using the Remote Control to Operate the
Mouse Pointer (Wireless Mouse)" p.55
I
USB(TypeA) port
• Connects a USB memory device or a digital camera,
and projects images as a Slideshow.
s "Projecting Without a Computer (Slideshow)"
p.47
• Connects the optional Document Camera.
J
S-Video port
For S-video signals from video sources.
K
Audio-L/R port
Inputs audio from equipment connected to the
Computer port, the S-Video port, or the Video port.
L
Monitor Out port
*
(EB-S12/EB-X11/EB-
S11 only)
Outputs analog RGB signals input from the Computer
port to an external monitor. You cannot output
signals input from other ports or component video
signals.
Name Function
M
Audio Output port
*
(EB-S12/EB-X11/EB-
S11 only)
Outputs the sound of the image currently being
projected to external speakers.
N
RS-232C port
(EB-X11/EB-S11 only)
When controlling the projector from a computer,
connect it to the computer with an RS-232C cable.
This port is for control use and should not normally
be used.
s "ESC/VP21 Commands" p.62
*
Depending on the area of purchase, the Monitor Out port and the Audio
Output port may not be available for EB-S12.
Part Names and Functions
12

Epson EB-X14 Specifications

General

Native aspect ratio	4:3
Projection distance	1.1 - 10.8 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	±30 °
Projector brightness (economic mode)	2400 ANSI lumens
Focus	Manual
Throw ratio	1.48 - 1.77:1
Focal length range	17 - 20 mm
Lamp type	E-TORL
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	5000 h
DVI port	No
AC (power) in	Yes
Audio (L/R) in	-
Composite video in	0
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
RMS rated power	2 W
Noise level	37 dB
Preset modes	Dynamic, Presentation, sRGB, Vivid photo
Country of origin	China
Noise level (economic mode)	29 dB
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
Power consumption (standby)	0.47 W
Power consumption (typical)	270 W
Pallet width	800 mm
Pallet height	2204 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Quantity per pallet layer	6 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	228 mm
Width	295 mm
Height	77 mm
Weight	2300 g
Package depth	360 mm
Package width	335 mm
Package height	158 mm
Package weight	3964 g
