Si
g
n
al
Re
fre
sh Ra
te
(
Hz
)
Res
o
l
ut
ion
(
d
o
t
s)
SDTV (480p)
60
720x480
SDTV (576p)
50
720x576
HDTV (720p)
50/60
1280x720
HDTV (1080i)
50/60
1920x1080
Composite
video
(EB-X14G/E
B-W02/EB-X02/EB-S02
only)
Si
g
n
al
Re
fre
sh Ra
te
(H
z)
Re
so
lut
i
o
n (
do
ts
)
TV (NTSC)
60
720x480
TV (SECAM)
50
720x576
TV (PAL)
50/60
720x576
Supported Monitor Displays
93
92
94
Table of Contents
Table of Contents
3
Notations Used in this Guide
2
Table of Contents
3
Introduction
6
Projector Features
7
List of Functions by Model
7
Quick and Easy Set Up, Projection, and Storage
8
Connecting with a USB Cable and Projecting (USB Display)
8
Detecting Projector Movements and Automatically Correcting Image Distortion (EB-X14G/EB-W02/EB-X02/EB-S02 Only)
8
Useful Functions for Projecting Images
8
Increasing Projection Content in Wide (WXGA) Screen (EB-W02/EB-W01 Only)
8
Making the most of the Remote Control
8
Enhanced Security Functions
8
Part Names and Functions
10
Front/Top
10
Rear
11
Base
12
Control Panel
13
Remote Control
14
Replacing the Remote Control Batteries
16
Remote Control Operating Range
17
Preparing the Projector
18
Installing the Projector
19
Installation Methods
19
Screen Size and Approximate Projection Distance
20
Connecting Equipment
22
Connecting a Computer
22
Connecting Image Sources
23
Basic Usage
25
Projecting Images
26
From Installation to Projection
26
Automatically Detect Input Signals and Change the Projected Image (Source Search)
27
Switching to the Target Image by Remote Control
28
Projecting with USB Display
28
System Requirements
28
Connecting for the First Time
29
Uninstalling
30
Adjusting Projected Images
32
Correcting Keystone Distortion
32
Correcting Automatically
32
Correcting Manually
33
Adjusting the Image Size
36
Adjusting the Image Position
36
Adjusting the Horizontal Tilt
37
Correcting the Focus
37
Adjusting the Volume
37
Selecting the Projection Quality (Selecting Color Mode)
37
Setting Auto Iris
38
Changing the Aspect Ratio of the Projected Image
39
Changing Methods
39
Changing the Aspect Mode
39
Useful Functions
42
Projection Functions
43
Hiding the Image and Sound Temporarily (A/V Mute)
43
Freezing the Image (Freeze)
43
Pointer Function (Pointer)
43
Enlarging Part of the Image (E-Zoom)
45
Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)
46
Saving a User's Logo
47
Security Functions
49
Managing Users (Password Protect)
49
Kinds of Password Protect
49
Setting Password Protect
49
Entering the Password
50
Restricting Operation (Control Panel Lock)
51
Anti-Theft Lock
52
Installing the Wire Lock
52
Monitoring and Controlling
53
ESC/VP21 Commands
53
Before Starting
53
Command List
53
Communications Protocol
53
Configuration Menu
54
Using the Configuration Menu
55
List of Functions
56
Configuration Menu Table
56
Image Menu
57
Signal Menu
58
Settings Menu
59
Extended Menu
61
Info Menu (Display Only)
62
Reset Menu
63
Troubleshooting
64
Using the Help
65
Problem Solving
66
Reading the Indicators
66
When the Indicators Provide no Help
69
Default Chapter
70
Problems Relating to Images
70
No Images Appear
70
No Images Appear S
70
Moving Images Are Not Displayed (Only the Moving Image Portion Turns Black)
71
Projection Stops Automatically
71
The Message Not Supported Is Displayed
71
The Message no Signal Is Displayed
71
Projection Stops Automatically S
71
The Message "Not Supported" Is Displayed S
71
The Message "No Signal" Is Displayed S
71
Images Are Fuzzy, out of Focus, or Distorted
72
Images Are Fuzzy, out of Focus, or Distorted S
72
Interference or Distortion Appear in Images
73
The Image Is Truncated (Large) or Small, or the Aspect Is Not Suitable
73
Interference or Distortion Appear in Images S
73
Image Colors Are Not Right
74
Image Colors Are Not Right S
74
Images Appear Dark
75
Problems When Projection Starts
75
The Projector Does Not Turn on
75
Images Appear Dark S
75
The Projector Does Not Turn on S
75
Other Problems
76
No Sound Can be Heard or the Sound Is Faint
76
The Remote Control Does Not Work
76
I Want to Change the Language for Messages and Menus
77
Maintenance
78
Cleaning
79
Cleaning the Projector's Surface
79
Cleaning the Lens
79
Cleaning the Air Filter
79
Replacing Consumables
81
Replacing the Lamp
81
Lamp Replacement Period
81
How to Replace the Lamp
81
Resetting the Lamp Hours
84
Replacing the Air Filter
84
Air Filter Replacement Period
84
How to Replace the Air Filter
84
Appendix
86
Optional Accessories and Consumables
87
Optional Accessories
87
Consumables
87
Screen Size and Projection Distance
88
Projection Distance (for EB-W02/EB-W01)
88
Projection Distance (for EB-X14G/EB-X02)
89
Projection Distance (for EB-S02/EB-S01)
90
Supported Monitor Displays
92
Supported Resolutions
92
Computer Signals (Analog RGB)
92
Component Video
92
Composite Video (EB-X14G/EB-W02/EB-X02/EB-S02 Only)
93
Specifications
94
Projector General Specifications
94
Appearance
98
Glossary
99
General Notes
101
About Notations
101
General Notice
101
Index
102
