Epson ESC/VP21 - Page 53

Bit Value
Bits 4-3 00
01
10
11
Bit 5
0
1
Bit 6 0
1
Bit 7
0
1
&D0 is selected,
&D1 is selected.
&D2 is selected. (default)
&D3 is selected.
&C0 is selected.
&C1 is selected. (default)
&S0 is selected. (default)
&S1 is selected.
Y0 is selected. (default)
Y1 is selected,
S22 Bit Mapped Options
Bit Value
Bits 1-0 00
01
10
11
Bits 3-2 00
01
10
11
Bits 6-4
000
001
010
011
100
101
110
111
Description
Reserved.
L1 is selected,
L2 is selected. (default)
L3 is selected.
M0 is selected.
M1 is selected. (default)
M2 is selected.
M3 is selected.
X0 is selected.
Reserved.
Reserved.
Reserved.
X1 is selected.
X2 is selected.
X3 is selected.
X4 is selected. (default)
46
S REGISTER REFERENCE - 3
