Epson EX3220 User Guide

3. Use the screwdriver included with the replacement lamp to loosen the screw securing the lamp
cover.
Warning: If the lamp is broken, glass fragments may be loose inside the lamp chamber. Be careful
removing any broken glass to avoid injury. If the projector is installed on the ceiling, stand to the side
of the lamp cover and not underneath it; pieces of glass could fall into your eyes or mouth when you
open the lamp cover.
4. Slide the lamp cover out and lift it off.

Epson EX3220 Specifications

General

Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.88 - 10.44 m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	10000:1
Screen size compatibility	- \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	30 °
Focus	Manual
Throw ratio	1.45 - 1.96:1
Focal length range	0 - 16.7 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+)
AC (power) in	Yes
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Component video (YPbPr/YCbCr) in	0
Noise level	37 dB
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop, Tripod
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	283 W
Power consumption (economy mode)	207 W
Sustainability certificates	RoHS
Cables included	AC, USB, VGA
Remote control type	IR
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	228.6 mm
Width	294.6 mm
Height	78.74 mm
Weight	2400 g
