Epson EX3220 User Guide

Rear
Front Ceiling
Rear Ceiling
Wherever you set up the projector, make sure to position it squarely in front of the center of the screen,
not at an angle, if possible.
If you project from the ceiling or from the rear, be sure to select the correct Projection option in the
projector's menu system.
Parent topic: Projector Placement

Epson EX3220 Specifications

General

Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	0.88 - 10.44 m
Projection technology	3LCD
Supported aspect ratios	-
Contrast ratio (typical)	10000:1
Screen size compatibility	- \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	30 °
Focus	Manual
Throw ratio	1.45 - 1.96:1
Focal length range	0 - 16.7 mm
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 800 (WXGA), 1400 x 1050 (SXGA+)
AC (power) in	Yes
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
USB 2.0 ports quantity	2
Component video (YPbPr/YCbCr) in	0
Noise level	37 dB
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop, Tripod
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	283 W
Power consumption (economy mode)	207 W
Sustainability certificates	RoHS
Cables included	AC, USB, VGA
Remote control type	IR
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Depth	228.6 mm
Width	294.6 mm
Height	78.74 mm
Weight	2400 g
