Epson EX7220 Operation Guide

1 Profile Displays the profile. You can drag and drop profiles and folders to change
the folder structure.
2 Copy Duplicates the profile. The copied profile is saved in the same folder as the
original with the same name.
3 Delete Deletes the profile and the folder.
4 Rename Displays the Rename dialog box to rename the folder or the profile. You
can enter up to 32 characters in the Rename dialog box.
5 Export Exports the profile. Exported profiles can be used as backup files. You can
import them on another computer.
6 Import Loads an exported profile.
7 Create folder Creates a new folder.
88

Epson EX7220 Specifications

General

Matrix type	3-panel (p-Si TFT active)
Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	0.9 - 9 m
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-30 - 30 °
Focus	Manual
Throw ratio	1.3 - 1.56:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.58 - 1.72
Lamp type	UHE
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Video processing	10 bit
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1440 x 1050, 1440 x 900 (WXGA+)
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	2
Noise level	37 dB
Noise level (economic mode)	29 dB
RMS rated power	2 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	Black
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	207 W
Power consumption (typical)	283 W
Operating temperature (T-T)	5 - 35 °C
Remote control type	IR

Weight and Dimensions

Depth	228.6 mm
Width	294.64 mm
Height	76.2 mm
Weight	2399.51 g
