11
Setting Up the Printer
5. Remove the new ribbon cartridge from the package. Remove the separator from
the middle of the ribbon cartridge and discard the separator. Then turn the ribbon-
tightening knob in the direction of the arrow to remove any slack in the ribbon.
6. Hold the cartridge with the ribbon-tightening knob up. Fit the two front notches
of the ribbon cartridge over the small pegs on each side of the printer as shown
below. Then lay the cartridge flat.
7. Make sure that the two rear notches of the cartridge fit over the small pegs on each
side of the printer. Then gently press down the cartridge until both ends click into
place.
separator
ribbon-tightening knob
