Confidential
Disassembly/Reassembly Overview 23
M200 / M205 / M100 / M105 Series
Revision A
2.1.4 Standard Operation Time for Servicing the Product
The following are the standard operation time for servicing the product. This standard operation time was
determined with the MTTR result measured using the prototype of M200/M205 Series which have the most
functions. For other models described in this manual, perform the repair work referring to this standard operation
time though the time varies due to the structural difference between models.
The underlined parts/units are supplied as After Service Parts.
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
Housing Rear 0:36 0:36
Paper Support 0:09 0:09
Paper Support Sub 0:23 0:23
Tray Front Assy 0:22 1:35 1:57
Tray Front 0:15 0:15
Tray Front Support 0:22 0:22
Paper Guide Front Unit
0:49 8:13 9:02
Waste Ink Pad Assy 0:42 0:45 1:27
Paper Back Lever 1:52 1:52
Retard Roller Assy
2:00 0:47 2:47
FFC Cover Outer 0:26 0:26
Holder Board
0:56 0:56
Printhead 2:20 18:47 21:07
ADF Paper Guide Cover Assy 0:25 0:25
ADF Cable Cover 0:27 0:27
Paper Support Cover
0:06 0:06
Document Mat 0:13 0:13
Adapter Cover
0:18 0:18
Ink Supply Tube Guide 1st 0:45 0:45
Tube Guide Sheet Sub
0:55 0:55
Tube Pressing Plate 0:34 0:34
Ink Supply Tube Guide 2nd 1:11 1:11
Joint
0:25 0:25
Adapter 0:33 0:33
Tube Guide Sheet
1:35 1:35
Ink Supply Tube
1:54 1:54
Star Wheel Holder Assy 1:34 1:34
Ink Supply Tank Cover 0:06 0:06
Ink Tube Cover 0:16 0:16
Ink Supply Tank Assy 1:54 1:54
Ink Supply Tank Side Porous Pad
1:25 1:25
Ink Supply Tank Upper Porous Pad 2:44 2:44
Cap 0:25 0:25
Valve Lever 1:08 1:08
Ink Supply Tank 1:32 1:32
Ink Supply Tank Tube Assy 1:32 1:32
To Next Page
