Epson SC-F9200 series

SC-F9200 Series Rev.A
15
<<Media Feeding Unit>>
Fix the parts at both sides by tightening screws (total: 4pcs).
Rear side
Set the Media Feeding Unit firstly from the left side as below.
Carry the Media Feeding Unit (approx. 34.3 kg) using 2persons,
each holding the 2bars as shown
C A U T I O N
Rear side
