Settings item Settings value
Change Reference Paper
Plain paper Display supported paper types
Matte Paper
Photo Paper
CAD
Others
Advanced Media Setting
Platen Gap 1.2, 1.6, 2.1
Top/Bottom Margins Standard, Top 3 mm/Bottom 3 mm, Top 15 mm/Bottom 15 mm, Top
35 mm/Bottom 15 mm
Paper Suction -4 to +3
Back Tension Auto, Standard, High, Extra High
Drying Time
Drying Time per Pass 0.0 to 10.0 sec
Drying Time per Page 0.0 to 60 min
Paper Size Check On, Off
Auto Cut On, Off
Remove Skew On, Off
Restore Default Yes, No
Printing Language
USB Auto, HP-GL/2
Network Auto, HP-GL/2
Universal Print Settings
Paper Source Roll Paper, Cut Sheet(1 sheet)
Quality Standard, Speed, Fine, Super Fine, Draft
Color Mode Color, Black/White
Page Margins option Clip By Margins, Oversize
Page Margin 3 mm, 5 mm
Smoothing On, Off
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series/SC-T3400N Series User's Guide
Using the Menu
120
