The printer driver's dialog box for this printer
appears.
D
Set Output Size and Source in the printer driver.
U “Basic Operating Procedures (Windows)”
on page 51
U “Basic Operating Procedures (Mac)” on
page 57
E
Select CAD/Line Drawing - Black, CAD/Line
Drawing - Color, or CAD/Line Drawing -
Bi-Level from the Select Target list.
Windows
Mac
F
Check other settings, and then start printing.
Note:
If the output size is portrait and the height is smaller
than the width of the roll paper, the print image is
printed rotated 90˚ to save paper. This function is
enabled if the Auto Rotate check box is selected in
Roll Paper Option on the Advanced tab.
SC-T5400 Series/SC-T5400M Series/SC-T3400 Series/SC-T3400N Series User's Guide
Printing with the Printer Driver from Your Computer
62
