6
Place the bottles to the left of the printer
as shown.
NEVER PLACE THE BOTTLES
HIGHER THAN THIS
(If the bottles are placed higher then the
ink may siphon into the bottom of the
printer.)
Make sure there are no twists in the
tubing.
Feed the cartridges through the opening in
the printhead lid. (If you have previously
removed this lid already do not worry as it
is not necessary for the operation of the
system).
Push the cartridges down firmly until they
snap into position. Close the printhead lid
making sure not to trap the tubing.
Remove the tape from the sticky pad and
firmly press the tube support into place as
shown Make sure the tubing is not
twisted..
