107
Appendix
Socket communication
For Ethernet interface
Communication specifications
10BASE-T/100BASE-TX
For Wi-Fi Interface
Specification
IEEE802.11b/g/n (2.4 GHz band) or IEEE802.11a/b/g/n/ac (2.4 GHz or 5 GHz band) compliant Wi-Fi
communication compatible.
Infrastructure mode is supported.
Support the IP address automatic acquisition function (DHCP, APIPA).
Communication Standard
IEEE802.11b (2.4 GHz)
IEEE802.11g (2.4 GHz)
IEEE802.11n (2.4 GHz)
IEEE802.11a (5 GHz)
IEEE802.11n (5 GHz)
IEEE802.11ac (5 GHz)
Security
Security can be selected from among the following:
WPA-PSK(AES)
WPA2-Personal
WPA2-Enterprise
Initial settings
These settings apply when the printer is initialized in the Interface Setup mode.
Port type TCP communication port for direct
printing
Port number 9100
Port communication direction bidirectional
Max. simultaneous connections 6
Number of connections for which printing is available 1 (occupied until the connection is
released.)
Time out: 90 seconds (changeable)
Countries where Wi-Fi can be used are limited. Since notes are provided for each country, check the
sheet supplied with the product.
When using wireless LAN, make sure you disconnect the LAN cable. If a LAN cable is connected,
wireless LAN is disabled.
