MultiQ Products AB provides NO support for application development of any kind. The information here is provided "as

is", and there is no guarantee that any of the examples shown will work in your particular application.

Technical Note – Epson TM-T88IV printer 6

Will give the following printout

Figure 2. Printout from above example code

In many it is desired not to display on screen the actual content that will be printed, here you may

place printout.html as a hidden frame and have it print immediately after being loaded. Printout will

be the same as in Figure 2.

Alternate printout.html code to print on load

<html>

40px text

In Italics

</body>

</html>

Of course the content of the webpage as well as the framed element can be changed for specific

applications. The code only contains the standard elements used when printing from web pages.

For applications not communicating with central systems, such as queue ticket systems or printout

of other information that is not updated very often it is advisable to publish the website to a zipped

folder that is stored in the media monitor itself. How this is done is described on pages 79-86 in

the DSMS3 Users manual that can be downloaded from the download page of the service &

support section of the MultiQ website.

Other manuals for Epson TM T88IV

Questions and Answers:

Need help?

Do you have a question about the Epson TM T88IV and is the answer not in the manual?

General

Dimensions (WxDxH)	145 x 195 x 148 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Type	POS printer
Character size	1.1 x 2.1 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL/CSA, TUV
Certification	CE, EN55022, EN55024, RoHS, WEEE
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, PDF417, UPC-A, UPC-E
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	White
Maximum roll diameter	83 mm
Supported paper width	72 mm
Operating temperature (T-T)	5 - 45 °C
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Power supply type	DC
Pallet width	800 mm
Pallet height	1837 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2250 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2780 g
Quantity per pack	1 pc(s)
