MultiQ Products AB provides NO support for application development of any kind. The information here is provided "as

is", and there is no guarantee that any of the examples shown will work in your particular application.

Technical Note – Epson TM-T88IV printer 5

3 Connect the Epson TM-T88IV printer

Connect the TM-T88IV printer to the media player/monitor using the USB cable. The printer should

be ready for use.

To initiate printing a print command has to be sent to the printer. In this application note one

possible way of doing this is described.

In this example we use a web page “printerpage.html” on which there is a button initiating the

printout of the content of a framed element contained in the file “printout.html” on the same page.

printerpage.html code

<html>

<head>

function printframe(frameid)

{

document getElementById(frameid) contentWindow print();

}

</script>

</head>

<body>

<input type="button" value="print iframe"

onclick="printframe(‘printcontent’)">

</input>

Style="display block"> <!--use style="visibility hidden" to hide

iframe… -->

</iframe>

</body>

</html>

printout.html code

<html>

<body>

<p>40px text

<i>In Italics</i></p>

</font>

</body>

</html>

Other manuals for Epson TM T88IV

Questions and Answers:

Need help?

Do you have a question about the Epson TM T88IV and is the answer not in the manual?

General

Dimensions (WxDxH)	145 x 195 x 148 mm
Standard interfaces	Ethernet
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Type	POS printer
Character size	1.1 x 2.1 mm
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL/CSA, TUV
Certification	CE, EN55022, EN55024, RoHS, WEEE
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, PDF417, UPC-A, UPC-E
Country of origin	China
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Product color	White
Maximum roll diameter	83 mm
Supported paper width	72 mm
Operating temperature (T-T)	5 - 45 °C
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Power supply type	DC
Pallet width	800 mm
Pallet height	1837 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Pallet height (UK)	2250 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2780 g
Quantity per pack	1 pc(s)
