Epson TM T88V Specifications

Printer Specifications TM-T88V
Epson TM
-
T88V POS Printer
Inch values are approximate.
dpi: dots per 25.4mm (dots per inch)
cpi: characters per 25.4mm (characters per inch)
lps: lines per second
*To find out more about our line of Connect-It interfaces,
talk to your Epson Sales Representative.
The Best-selling Thermal Printer
Just Got Even Better
Optional power supply case
secures cords under printer.
Optional mounting bracket available
for hanging printer on wall.
General Print method Thermal line printing
Print fonts
  Fonts FontA(default):12x24;FontB:9x17(including2-dothorizontalspacing)
  Columncapacity(A,B) 80mm:42/56columns;58mmmodel:30/40columns
  Charactersize FontA:1.41x3.39;FontB:0.99x2.40(WxHmm)
  Characterset 95Alphanumeric,18International,128x43Graphic(includinguser-definedpage)
   Traditional/SimpleChinese,Thai,Japanese,Korean
  Barcode UPC-A/E,CODE39/93/128,EAN8/13,ITF,CODABAR2Dsymbols:PDF417,
QR-CODE,MaxiCode,CompositeSymbology,GS1-128,
GS1DataBarOmnidirectional/Truncated/Limited/Expanded
Printer Interfaces Built-inUSBinterface+anotherselection:serialRS-232C,parallelIEEE-1284,high-speed
USB,poweredUSB,Ethernet10/100Base-T/TX,wireless,oraConnect-It*interface(Only
oneinterfacecanbeusedatatime.)
 Databuffer Receive:45bytesor4KB,selectable;user-defined:12KB;macro:2KB;
NVgraphics:256KB;NVuser:1KB;pagemodearea:106K
 Printspeed(max.) 11.8”/second(300mm)graphicsandtext;2.4”/secondforladderand2Dbarcodes
 Paperdimensions 80mm:3.13”±0.02”x3.27”diameter(79.5±0.5(W)x83mm)
   58mm:2.26”±0.02”x3.27”diameter(57.5±0.5(W)x83mm)
 Paperthickness 55–80µm
 Power 24VDC±7%
 Powerconsumption Operating:approx.1.8A(mean)
 D.K.D.function 2drivers
Reliability
  MTBF 360,000hours
  MCBF 70,000,000lines
Autocutter 2 million cuts
 Overalldimensions 5.71x7.68x5.83”(WxDxH)(145x195x148mm)
 Weight 3.5lb(1.6kg)
 Color ECW,EDG
 Factoryoptions Powersupplycover,PS-180ACadapter,wall-hangingbracket,affixingtapeand
   Connect-Itinterfaces*
 Printersoftware DriversandsetuputilityareavailableonCDoratpos.epson.com
Control Board EMIstandards FCC/ICES-003ClassA
 Safetystandards UL1950/CSAC22.2No.950
1
There are many configurations of the TM-T88V. To find out which TM-T88V configurations are ENERGY STAR qualified
go to pos.epson.com/products/TM-T88V.htm.
Epson America, Inc. • 3840 Kilroy Airport Way • Long Beach, CA 90806 • (562) 290-5304 • http://pos.epson.com
©2010 Epson America, Inc. Epson is a registered trademark and Epson Exceed Your Vision is a registered logomark of Seiko
Epson Corporation. Connect-It is a trademark of Epson America, Inc. All other trademarks are property of their respective
owners. Specifications are subject to change without notice.
SD-DST885B

Epson TM T88V Specifications

General

Dimensions (WxDxH)	145 x 195 x 148 mm
USB port	Yes
Standard interfaces	RS-232, USB 2.0
Serial interface type	RS-232
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Type	POS printer
Print speed	11.8 ips
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Safety	UL1950/CSA C22.2 No. 950
Certification	FCC/ICES-003
Built-in barcodes	2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF-14, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Country of origin	China
Autocutter durability	2 million cuts
Mean time between failures (MTBF)	360000 h
Product color	Black
Maximum roll diameter	83 mm
Supported paper width	80, 58 mm
Printing media thickness	55 - 80 µm
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Input current	1.8 A
Power supply type	DC
Pallet width	800 mm
Pallet height	2550 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	128 pc(s)
Quantity per pallet (UK)	192 pc(s)
Master (outer) case width	400 mm
Quantity per pallet layer	16 pc(s)
Master (outer) case height	255 mm
Master (outer) case length	490 mm
Quantity per pallet layer (UK)	24 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	257 mm
Package width	193 mm
Package height	241 mm
Package weight	2660 g
Quantity per pack	1 pc(s)
