1-2 System Preparation Rev. B
Confidential
The maximum transmission speed is 115.2k bps when using a serial interface.
(*) Handshaking, communications speed, data bit length and parity are set by DIP switches on the TM Printer.
Interface Cable
Prepare a serial or USB interface cable according to customer requirements. Note that while the
standard serial interface of the TM printers uses a 25-pin D-sub connector, the UB-U09 uses a
9-pin D-sub connector.
Table 1-1 shows the recommended wiring for the interface cable.
Supported standard EIA/TIA RS-232 standard compliant
Data transfer method Bit Serial
Synchronization (Asynchronous)
Handshaking* DTR/DSR or XON/XOFF control
Signal level Mark: -3 to -15 V = Logic 1, OFF
Space: +3 to 15 V = Logic 0, ON
Communications speed*
(Baud rate)
115200 bps maximum
Data bit length* 7 or 8 bits
Parity* None, Odd or Even
Stop bits One or more bits
Table 1-1 Recommended wiring
Host side UB-U09 side (Female 9-pin D-sub)
--- Pin 1 not connected
TXD Pin 2 RXD
RXD Pin 3 TXD
DSR Pin 4 DTR
SG Pin 5 SG
DTR Pin 6 DSR (*1)(*2)
CTS Pin 7 RTS
Reset Pin 9 INIT(*2)
Frame GND Frame GND
