Epson XP-610

Hardware Setup Guide
Loading Paper
Step 1
Make sure the printer's control panel is displaying the home screen as shown below, and then open the front cover and
pull out the lower cassette (paper cassette 2).
The printer has a lower cassette and an upper cassette. Make sure you pull out the lower cassette.
Step 2
Slide the edge guides to adjust to the paper size.
Epson NPD4921-00 EN
Hardware Setup Guide
7
