EQUATION CUBE 6 User Manual

007 - Flame problem
- Lack of pellets.
- Température de la fumée
très basse.
------------------------------
008 - Black Out
- Lack of electricity more
than 5 s.
To reload press key 1
009 - Security entry
The pressure switch unactivated:
- Door open.
- The pipe is blocked, low air
call, the installation is not in
the established standards.
- Pressure switch pipe
blocked.
- Smoke extractor malfunction.
- Pressure switch broken.
- 120º temperature control
active or damaged.
Intervention of the 120º
temperature control
- Anomalous intervention due
to a burr on the base of the
temperature control.
- Pellets loader overheat.
- Damaged circuit board.
Temperature control
manual restart
- Air fan damaged moving.
- Incorrect operation parameters.
- Triac (extraction engine)
malfunction on the circuit board.
- Damaged temperature controller.
CABLE
- Wrong connection of 2 plugs
on the circuit board.
- Plugs not connected.
- Damaged plugs.
012 - Smoke temperature error
- If during ignition, smoke
sensor does not read the
temperature variation during
5 minutes it means that the
circuit board is damaged.
013 - Smoke extractor alarm
- Wrong circuit board connection.
Apears during ignition.
- Wrong plug connectio.
- Engine or encoder damaged.
(deactivate technical menu).
Clean the wood stove.
5.0 Cleaning and mantain
Annex:
Quick security and ignition
guide
.
------------------------------
------------------------------
------------------------------
Make sure that during ignition
you have some pellets.
------------------------------
Display will turn on when
the wood stove will be powered.
Contact the technical
assistance center.
Contact the technical
assistance center.
Contact the technical
assistance center
.
Contact the technical
assistance center.
Contact the technical
assistance center.
Contact the technical
assistance center.
Contact the technical
assistance center.
120
