INSTALLATION
Rolls Assembly
Connection
50-60Hz
• This device is mobile type and can be moved while respecting the safety
instructions.
• The appliance must be earthed.
• Connect the plug to a 220-240V 50/60Hz wall socket
• Unplug the appliance when it is not in operation
• A reel allows the cable to be stored safely
Important !
• Make sure to unwind the cable completely before plugging it in.
• Never handle the radiator while holding it by the reel
1 - Place heater upside down 2 - Insert U type screw. 3 - Place the plate on the hook of
the U type screw
4 - Insert the threaded part 5 - Tighten using the wing nut 6 - The other plate has to be
fixed directly on the heater.
