INSTALLATION
Choose a location that meets these criteria:
• The ground must be flat and stable
• A distance of 50 cm between the walls and the appliance must be
respected
• The device must be plugged into a wall outlet which must remain
accessible once the device is plugged in.
• It is essential to connect the external exhaust for use in cooling
mode or in dehumidification mode
Connection of the exhaust duct
Connection is mandatory for use in Cooling or Dehumidification
mode, but not necessary in Ventilation mode.
>50cm
>50cm
>50cm
220-240V
50Hz
A
B
C
The exhaust duct can be connected into a wall or installed to a window
using a draught-proofing kit (not included).
1 - Fix adaptor A (device connection) on the pipe
2 - Fix adaptor B (window connection) on the pipe if necessary
3 - Clip adaptor A onto the device
4 - Connect the hose to the outside outlet.
Inserting batteries
1 - Press gently on the cover of the
battery compartment and push
it in the direction of the arrow in
order to remove it.
2 - Insert 2 AAA (LR03) 1,5V batte-
ries in the compartment
Make sure you observe the right
polarity (“+” and “-”).
3 - Place the cover of the battery
compartment back..
43
EN
