Equator PLS600V - Page 15

EQUATOR ADVANCED Appliances
Service Manual : COMPACT DISHWASHER – PLS 600 / 602 SERIES
Page 15
Pos# PART# DESCRIPTION
22 4122-0029 Door Locking Hook PLS-602
23 4122-0024 HINGE FOR DOOR PLS 602 RIGHT
24 4122-0060 HINGE FOR DOOR PLS 602 LEFT
25 5122-0009 Main Water Sprinkler PLS-602
26 4122-0001 Base of Main Sprinkler PLS-602
27 4123-0002 O-Ring for Base of Main Srinkler PLS-602
28 4122-0022 Clip, Lower Spray arm
29 4122-0007 Filter PLS
30 4122-0017 Filter Collector PLS-602
31 4122-0018 Filter Separator PLS-602
32 4122-0019 Base of Filter Collector PLS-602
33 1709-0021 Heating Element PLS 120V-1200W (UL)
34 1412-0003 E-Bracket for PLS Heating Element
35 1411-0007 Nut M5 irid din 985
36 1411-0009 Safety Nut m5 irid din 985
37 1501-0005 Fast on Angled Male Terminal 6,3x0,8
38 4121-0004 Bracket for Heating Element PLS-602
39 1705-0006 Safty Thermostat PLS
40 1705-0005 Temperature Thermostat PLS
41 4113-0001 Flang for Thermostat sup. aut
42 5126-0002 Presostat PLS601 assembled
43 1703-0004 Rinse Aid Dispenser 120v/60Hz UL Mark
43.1 1010-0001 Bung of Rinse Aid Dispencer 526
44 4121-0002 Door Microswitch PLS-602
52 4122-0050 Constrictor '19
57 1701-0008
Main Pump Hanning DP-60C-093 120V/60Hz UL Mark( main
pump bottom jet)
57.1 1402-0009 Flange of Pump Hanning BE-53/54
58 5121-0030
Pump Hanning DPS25-055 120v/60Hz Prepared for B'Sprinkler
( top jet )
59 1701-0018 Pump Hnning DPS 25-054 120v/60Hz UL Mark-- Drain
60 4123-0004 Ruber Hose'22X4 50mm for Pump PLS-602
61 4123-0008 Ruber Hose for Secondary Presure Pump PLS-602 S
62 1001-0003 Hose '12x18 75cm
63 4122-0004 Constrictor 32
64 1401-0004 Fastening tie 13.5cm
65 5126-0022 Water Valve 319 ( single )
