Service Manual : COMPACT DISHWASHER – PLS 600 / 602 SERIES
Page 14
PARTS LIST
Pos# PART# DESCRIPTION
1 5126-0044 Tub PLS-602 Reinforced( ul construction )
2 4122-0010 Housing PLS-602
3 5126-0036 DOOR PLS-602 WITH HANDLE ASSEM.
3.1 4122-0072 DOOR FOR PLS 602S
3.2 5126-0008 DOOR HANDLE PLS-602 WHITE COMPLETE
3.2.1 4122-0082 COUNTERTOP DISHWASHER HANDLE
3.2.2 4122-0049 Door Latch PLS-602
3.2.3 4112-0008 Door Handle Bracket sup.aut.
3.2.4 1403-0001 Door Handle Spring 0,7x8,5x21
4 5122-0010 Bottom Cover PLS-602 with soft feet assembled
5 4122-0015 Back Cover PLS-602
6 5120-0016 Galv/Alumin Painted PLS-602
7 5120-0012 Panel of Timer PLS-602-S Equator
8 5126-0041 Button for Timer PLS-602 White complete
9 5120-0013 Panel of Indicating Lamps PLS-602-S
10 4122-0083 Button of Temperature/N-F Switch PLS-602
11 4122-0071 Monitor for Indicating Lamp Panel PLS-602 120'F/150'F
12 4122-0031 CASTOR OF GROCERY CARRIER PLS-602
13 4122-0021 Cover of Water Vapour Emptying Sluice PLS-602
14 5126-0030 Rod for Door Switch PLS-602 Assembled
14.1 5121-0010 Rod for Door Switch PLS-602 Shaped
14.2 4122-0065 Door Switch Cover PLS-602
14.3 4112-0010 Head of Door Switch Rod Sup.Aut
14.4 1406-0002 Grooved Washer -3 inox
14.5 4111-0013 Washer 3,2x8 inox
14.6 1403-0003 Spring inox 0,6x5x90
15 4122-0076 Base of Secondary Water Sprinkler PLS-602 S
16 4123-0012 Flange 25x38mm (for the base secondary water sprinkler pls )
17 4122-0056 Nut for Base of Secondary Water Sprinkler PLS-602
18 4122-0055 Ring for Secondary Water Springkler PLS-602 S
19 5122-0008 Secondary Water Spinkler PLS-602
20 4122-0057 Clip, Upper Spray Arm
21 4122-0063 Tubular Flange of Door Switch Rod PLS-602
