QUICK START GUIDE
CONNECTIONS
INSTALLATION
Unscrew shipping bolts at back Pull out shipping bolts (2) Fit back the 2 screws
Plug power cord into
110V/60Hz/15A outlet
Place drain hose into a sink
or standpipe 24”-40” high
Attach 4” vent hose to the
exhaust outlet for venting option
using adapter included.
Connect hot & cold water hoses
Wash & Dry: Turn knob
clockwise to Wash setting -
Set Dryer time (+/-)
Select options - START
Wash Only: Turn knob
clockwise to setting -
START
Dry Only: Turn knob
to Dry selection -
Set Dryer time (+/-)
START
OPERATION
Load the machine to a
maximum 2/3 full
LAUNDRY PREP
Important: Use High-Efficiency(HE)
Detergent-approx. 1 tablespoon
Press Venting/Condensing
button for 5 seconds to
select drying option
Use liquid fabric softener.
Items tumble more freely
and dry faster
CONNECTIONS
Open coin trap door, rotate handle
counter-clockwise, clean interior
fix cover back, close flap.
MAINTAINENCE
Close the empty space with
the blanking plug enclosed.
