RATING LABEL EXPLANATION
EAG18-Li=MODEL NUMBER E=Erbauer
AG=Angle Grinder
18 = 18V d.c.
Li = LITHIUM ION
PRODUCT DESCRIPTION
1. Spindle lock button
2. Mounting threads (×3)
3. ON /OFF switch
4. Gripping surface
5. Battery pack release button
6. Power bar button
7. Battery pack (not included)
8. Filter cover (×2)
9. Auxiliary handle
10. Grinding safety guard
11. Guard clamping lever
12. Clamp adjustment screw
13. Spindle
14. Inner ange
15. Grinding/Cutting wheel (not included)
16. Outer ange
17. Spanner
18. Cutting safety guard
01
TECHNICAL SPECIFICATIONS
Rated voltage: 18V d.c.
Rated speed n: 8500/min
Spindle thread M14
Maximum wheel diameter Ø115mm(4 1/2”)
Maximum thickness of grinding wheel 6mm
Wheel bore Ø22.23mm
Weight (without battery): 1.8 kg
Ambient temperature range for tool and battery use: -10°C to 40°C
For use with battery pack and charger as below:
Battery pack model: EBAT18-Li-2 / EBAT18-Li-4 / EBAT18-Li-5
Charger model: EC18-Li / EFC18-Li / EMC18-Li
NOISE DATA
A weighted sound pressure: L
pA
: 82.0dB (A)
A weighted sound power: L
wA
: 93.0dB (A)
Uncertainty: K
PA
& K
WA
=3.0dB(A)
The noise for the operator may exceed 80 dB(A) and ear protection measures are
necessary.
VIBRATION DATA
Surface grinding a
h,AG
=2.8m/s²
Uncertainty K =1.5m/s²
