29
2. Loosen the xation lever (20a) and adjust the base plate to the desired depth. Use
the depth scale (20b) as a guide.
3. Tighten the xation lever (20a) to secure the cutting depth.
NOTE: The values shown on the depth scale are only valid for cutting at
90°/0°! For bevel cuts the cutting depth will be smaller than indicated and
should be determined by trial cut.
02
Bevel angle adjustment (Fig. E)
Adjust the cutting angle according to your needs.
1. Place the product on a at surface.
2. Loosen the xation knob (6a) and tilt the housing to the desired angle. Use the
scale (6b) as a guide.
3. Tighten the xation knob (6a) to secure the angle selected.
03
On/Off switch & Lock-off button (Fig. F)
1. Press the lock-off button (19) and hold it in position.
2. Press the on/off switch (18) to switch the product on.
3. Release the on/off switch (18) to switch the product off.
04
On/Off switch for laser device
Use the laser as a guide when cutting on marked lines.
1. Press the on/off switch for laser device (23) to switch the laser on.
2. Press the on/off switch for laser device (23) again to switch the laser off.
WARNING! Do not stare into the beam, class 2 laser product!
