Erbauer EHP1050 - Dust Extraction; Dust Bag

02
Dust extraction (Fig. A and B)
WARNING! Always attach a dust extraction device or the dust bag when
using this product to keep the working area clean! Wear a dust mask
when operating this product! Dust can be harmful to health! Especially
dust and chips of wood that has been treated, e.g. with wood preservative
or a stain!
Dust/Chip extraction guide switch
To select the dust extraction outlet (5) on the right/left hand side of the product, by
move the dust / chip extraction guide switch (9) up or down.
Dust bag
1. Align the connector of the dust bag (22) to the dust extraction outlet (5) and insert
it completely (Fig. A).
2. Pull the connector out in a twisting motion to remove the dust bag (22).
Emptying
1. Remove the dust bag (22) from the product as described above.
2. Open the zip and empty chippings into a suitable rubbish bag.
3. Close the zip and re-attach the dust bag (22) to the product.
NOTE: Empty the dust bag when it is half full. An overlled dust
bag lowers the performance of the product.
Dust extraction
Attach a proper dust extraction device, e.g. a suitable vacuum cleaner attachment
(Ø35mm) to the dust extraction outlet (5) (Fig. B).
