Parallel guide (Fig. C)
Attach the parallel guide to perform straight planing cuts along a workpiece edge.
1. Align the hole in the angle bracket (24b) to the mounting thread (10) and x it with
a wing screw (24a) (Fig. C, Step 1).
2. Attach the parallel guide (24e) to the angle bracket (24b). Fix it with the mounting
bolt (24c) and wing nut (24d) (Fig. C, Step 2).
3. Adjust the parallel guide (24e) to the desired width.
4. Tighten the wing nut (24d).
04
Rebate depth gauge (Fig. D)
Adjust the rebate depth gauge (1) to perform rebate cuts.
1. Loose the locking lever (2) and adjust the rebate depth gauge (1) to desired depth.
2. Tighten the locking lever (2).
