29
8. Release the spindle locking button, remove the hex key and turn the saw/diamond
blade by hand to check if it rotates smoothly. The blade should not utter.
9. Switch the product on and let it run at no-load speed for about one minute to
ensure that the saw/diamond blade has been installed properly. If there is any
abnormal vibration or excessive noise, switch the product off and re-t the saw/
diamond blade according to the above instructions.
03
Parallel guide (Fig. F)
Attach the parallel guide to perform cuts parallel to the workpiece edges.
1. Loosen the parallel guide clamping bolt (18) anti-clockwise with the hex key (20)
(Fig. F step 1).
2. Align the parallel guide (6) with the two brackets and insert it through them (Fig. F
step 2).
3. Use the scale to adjust the desired width.
4. Secure the parallel guide (6) in position by tightening the parallel guide clamping
bolt (18) clockwise.
04
Replacing the batteries of laser (Fig. G)
1. Slide and open the cover of the laser battery compartment (10).
2. Insert 2 button cell batteries of type LR44H as indicated. Please pay attention to
the cell polarity marked on the housing.
3. Close the laser battery compartment (10) cover and slide to x it in position.
05
Dust extraction (Fig. H)
WARNING! Always attach a dust extraction device when using this
product to keep the working area clean!
Wear a dust mask when operating this product! Dust can be harmful to
health!
Attach a proper dust extraction device, e.g. a suitable vacuum cleaner attachment
(Ø35mm) to the vacuum cleaner adaptor (16) and then attach to dust extraction outlet
(17).
650W Mini circular saw_MNL_EMCS650_TPS_GB_V02_V20518_20180604.indd 29 6/4/18 09:20
