ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your Local Authority or retailer for recycling
advice.
PLUG REPLACEMENT
The fuse in the main plug of your power tool
should always be replaced with one of identical
rating.
Check the voltage given on your power tool
matches the supply voltage.
The power tool is supplied with a fitted plug,
however if you should need to fit a new plug
follows the instruction below.
IMPORTANT
The wires in the mains lead are coloured in
accordance with the following code:
Green & yellow - Earth
Blue - Neutral
Brown - Live
The wire which is coloured green & yellow must
be connected to the terminal which is marked
with
E or
.
The wire which is coloured blue must be
connected to the terminal which is marked with
N. The wire, which is coloured brown, must be
connected to the terminal, which is marked with
the letter
L.
A 13AMP (BS1363 or BS1363/A) plug must be
used and a 13 AMP fuse must be fitted.
Fig 10
Fig
9
Fig 12
Fig 11
Inner flange outer flange
Diamomd
wheel
Spacing
plate
Blade
guard
cover
Wrench A
Wrench
B
