ROUTER
TECHNICAL DATA
Voltage: 230V~50Hz
Input power: 2100W
No load speed: 8,000-23,000min
-1
Max. plunge depth: 60mm
Double insulation:
Weight: 6.5Kg
NOISE AND VIBRATION DATA
Sound pressure level: 89dB (A)
Sound power level: 102dB (A)
Vibration level: <3.64m/s
2
ACCESSORIES
1/2” collet (ready fitted): 1pc 1/4” collet: 1pc
Vacuum adaptor:
1pc Parallel guide: 1pc
Spanner: 1pc Trammel point: 1pc
30mm Guide bush: 1pc
9. ROUTING BASE
10. PARALLEL GUIDE LOCKING SCREWS
11. DUST OUTLET
12. PLUNGE LOCK LEVER
13. CARBON BRUSH COVER
14. MICRO DEPTH ADJUSTMENT KNOB
15. VARIABLE SPEED SWITCH
16. DEPTH BAR ADJUSTMENT SCREW
17. DEPTH BAR MEASURE GUIDE
18. TRAMMEL POINT
19. 30MM GUIDE BUSH
20. SPANNER
21. 6.35MM COLLET (1/4’’)
