Erbauer ERB2151SE - Technical Data; Noise and Vibration Data; Accessories

W
11
ERBAUER 216MM (8”) SLIDING MITRE SAW
Sound pressure level: 96.4 dB (A)
Sound power level: 109 dB (A)
Vibration level: 6.75 m/s
2
NOISE AND VIBRATION DATA
NOISE AND VIBRATION DATA
TECHNICAL DATA
TECHNICAL DATA
Volts: 230V~50Hz
Power input: 1800W S6, 20%, 10min.
No-load speed: 4800min
-1
Double insulation:
Net weight: 14.2 kg
Blade:
Ø216 mm ; Ø30 mm Bore
Turntable Ø230 mm
Mitre stops 0° ,15°, 22.5°, 31.6°, 45° left & right
Mitre angle range 45° left & right
Bevel angle range 0° to 47° left
Maximum capacity
Cross cut 62×305 mm
Mitre cut at 45° 62×212 mm
Bevel cut at 45° 30×305 mm
Compound cut at 45° 30×212 mm
Blade Spanner 1 pc
Dust Bag 1 pc
Hold-Down Clamp 1 pc
Mitre Handle 1 pc
ACCESSORIES
ACCESSORIES
