Erbauer ERB2151SE - Page 9

W
9
ERBAUER 216MM (8”) SLIDING MITRE SAW
1.
1.
DUST BAG
DUST BAG
2.
2.
UPPER BLADE GUARD
UPPER BLADE GUARD
3.
3.
CUTTING HANDLE
CUTTING HANDLE
4.
4.
LOWER BLADE GUARD
LOWER BLADE GUARD
5.
5.
BLADE
BLADE
6.
6.
TABLE INSERT
TABLE INSERT
7.
7.
MITRE HANDLE
MITRE HANDLE
8.
8.
LASER GUIDE
LASER GUIDE
9.
9.
BASE
BASE
10.
10.
TURNTABLE
TURNTABLE
11.
11.
LEFT EXTENSION TABLE
LEFT EXTENSION TABLE
12.
12.
FENCE
FENCE
13.
13.
HOLD-DOWN CLAMP
HOLD-DOWN CLAMP
14.
14.
SLIDE CARRIAGE LOCK KNOB
SLIDE CARRIAGE LOCK KNOB
Fig 1
1
2
3
4
7
8
9
10
11
12
13
5
6
14
KNOW YOUR SLIDING MITRE SAW
KNOW YOUR SLIDING MITRE SAW
