increase the stability of the table saw during operation.
Brake (Fig. U)
1. Press down on the side with “OFF” until the brake pedal (75) is parallel to the floor
to lock the transport wheels (12).
2. Press down on the side with “ON” on the brake pedal (75) to unlock the transport
wheels (12).
07
Laser (Fig. G, I)
Use the laser as guide when cutting on marked lines.
1. Switch the laser on by pressing the “I” of the laser on/off switch (43).
2. Switch the laser off by pressing the “O” of the laser on/off switch (43).
The laser line should be aligned with the blade cutting path. Readjustment of the laser
refer to “Assembly-Laser”.
08
Push stick (Fig. Z)
Push stick (16) is a device used for safely pushing a work piece through the blade
instead of using your hands. They can be made from scrap wood in various sizes and
shapes to be used in a specific project. The stick must be narrower than the work piece,
with a 90° notch in one end and shaped for a grip on the other end.
Use a push stick whenever the fence is 12 cm or less from the blade. Push stick should
be used in place of the user’s hand to guide the material between the fence and blade.
When using a push stick, the trailing end of the board must be square.
A push stick against an uneven end could slip off or push the work piece away from
the fence.
The push stick can be stored in the push stick storage (19).
09
Switching on/off and overload reset button (Fig. AA)
1. The product can be switched on by pressing the green “I”-Button on the
on/off switch (15).
2. The product can be switched off by pressing the red “0”-Button on the on/off switch
(15).
3. If the table saw overheats it will shut down automatically. Allow it to cool down for
15 min, and then press the overload reset button (9) to restart the table saw.
Operation
For safety reasons, verify that the operator has read the section entitled general safety
guidelines for the table saw before operating this saw. Verify the following before every
time the table saw is used:
