Parts list 77205 (version 01042006)
No.
PART DESCRIPTION Quantity No. PART DESCRIPTION Quantity
1
HEX. SCREW 2
42
Pin 1
2
LIFT HANDLE 1
43
Nut,M5 3
3
PLASTIC HOOD 1
44
Motor assembly(motor,switch
capacitor,switch
box,cable+plug,motor cover
rear,shroud,fan）
1
4
SCREW 4
45
Bolt ,M8*30 9
5
HYDRAULIC CYLINDER 1
46
Spring washer,8 11
6
Piston 1
47
Washer, 8 9
7
Piston ring 1
48
Spring 1
8
Rubber seal 1 49 Steel Ball, 6 1
9
Stud bolt 4 50 O-ring 2
10
Aluminium plug-real 1 51 Screw 1
11
Plastic gasket 1 52 O-ring 1
12
Cylinder rod 1 53 Screw plug 1
13
Pin 1 54 Screw 1
14
Nylon sleeve 2 55 Lever Guard 1
15
Log pusher 1 56 Hex screw 2
16
Spring guard (L) 1 57 Lever 1
17
Spring rod 2 63 Back bracket 1
18
Tube frame 1 64 Ping shaft 1
19
Retract Spring 2 58 Lever knob 1
20
Spring hood bracked 4 59 Wheel cap 2
21
Screw ,M6*10 16 60 Snap ring 2
22
Spring washer,6 8 61 Wheel 2
23
Spring guard (R) 1 62 Wheel shaft frame 1
24
Carriage Bolt 5 65 Snap ring 1
25
Nut,M8 7
66-
71
Valve control assy. 1
26
Support 1 72 Rubber seal 1
27
Bolt ,m8*30 1 73 Aliminium plug-front 1
28
Gear Pump 1 74 Spring 1
29
Sleeve bearing 4 75 O-ring 1
30
O-ring 2 76 Screw plug 1
31
Circlip 2 77 Copper gasket 4
32
Pin ,B8*24 2 78 Cap nut 4
33
Steel Ball,2.5 1 79 O-ring 1
34
Shaft 1 80 Bleed screw 1
35
Gear 2 81 O-ring 1
36
Gear housing plate 1 82 Dipstick 1
37
Bolt ,M5*185 3
38
Motor Cover-front 1
39
Washer 4
40
Spring washer,5 5
41
Gasket 1
