Ergotron LX Assembly Instructions

3 of 28
888-45-277-W-03 rev.G • 06/14
ABCD
1
2
ABCD
1
2
3
13 mm
2
1
1/4-20 x 1/2"
1/4-20 x 2"
M4.2 x 25mm
1x
1x
1x
1x
2x
4x
4x
2x
2x
2x
1x
1x
1x
9x
2x
1x
1x
2x
12x
7x
7x
14x
14x
2x
2x
7/16"
M4 x 14mm
2x
Ø 3/16" (5mm)
Ø 3/8” (10mm)
M10 x 16mm
6mm
ENGLISH
Components
Tools Needed
Stud Finder
Wood Stud Mounting
Concrete Wall Mounting

Ergotron LX Specifications

General

Product Type	Monitor Arm
Tilt	75°
Pan	360°
Rotation	360°
VESA Compatibility	Yes
VESA Mount Standard	MIS-D
Material	Aluminum
Warranty	10 years
Mounting Options	Grommet
Weight Capacity	7-25 lbs (3.2-11.3 kg)
Extension	25 inches (64 cm)
Lift	13 inches (33 cm)
Vertical Travel	13 inches (33 cm)
Color	White, Black
