888-33-332-W-02 rev.G • 11/15
11 of 12
B
C
4mm
12
a
b
4x
M5 x 8mm
ENGLISH
Adjustment may take up to: 115 full 360° revolutions
How to attach optional CPU holder ordered separately
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
To Next Page
