888-33-332-W-02 rev.G • 11/15
10 of 12
A
14mm
WARNING
A primary mechanism within the
tower is under tension and can
be hazardous to people
exposed to it under certain
extreme conditions. DO NOT
open the tower; DO NOT attempt
to service the cart/stand. DO NOT
remove safety guards or labels
designed to protect or inform of
possible hazards. Only
Ergotron-approved installers may
service or otherwise modify
cart/stand. Failure to heed this
Warning may result in serious
Personal Injury and Damage both
to the cart/stand and equipment.
STORED ENERGY HAZARD!
DO NOT OPEN TOWER OR REMOVE
SAFETY GUARD!
822-959-00
11
ENGLISH
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
Adjustment may take up to: 72 full 360° revolutions
Adjustment Step
Important! You will need to adjust this product after installation is complete. Make sure all your equipment is
properly installed on the product before attempting adjustments. This product should move smoothly and easily
through the full range of motion and stay where you set it. If movements are too easy or diffi cult or if product
does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
Depending on your product and the adjustment, it may take many turns to notice a difference. Any time
equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you
should repeat these adjustment steps to ensure safe and optimum operation.
