Item no: 07708
Extended arm 2x
M12* 30 hexagon bolt 2x
7. Attach the extended arms (14) with a M12*30 Hexagon Bolt (15).
6. Attach the supporting arm(13) and Parallel supporting frame(16) to the post, tighten with M12 lock nut(17)
and M12*55 hexagon bolt(2).

M12*55 hexagon bolt
parallel support frame 2x
M12 locknut 6x
supporting arm 2x
