Item no: 07601
Installation
Step 1 Insert the assembled Big Bed ‘High-Mount Adapter’ apparatus into a 2 inch receiver hitch (not
included). Install hitch pin (not included) to secure the Big Bed.
Step 2 Ensure the apparatus is secure to the vehicle. Spread the apparatus (K).
Step 3 Ensure the height of the vehicle cab/sports rack is equal to Big Bed ‘High-Mount Adapter’. The
height can be raised/lowered by adjusting the locking pin (B & C) in part (F & K)
Step 4 Evenly distribute the load across the Big Bed ‘High-Mount Adapter’. Fasten the load
securely with load appropriate tie-down straps.
Step 5 Secure a red flag to mark the end of the load. If hauling in the evening fasten a light to the load
to mark the end of the load.
3/4
F
L
K
K
A
F
G
H
C
E
D
B
F
L
L
