Command Description Page
Snmp
Display the configuration parameters for SNMP.
System name – The configured system name
System location – The configured system location
System contact – The configured system contact
Read community – The SNMP community for read (get)
operation
write_community – The SNMP community for write (set)
operation
trap community – The SNMP community for a trap
Trap receiver 1 – The IP address of trap receiver 1
Trap receiver 2 – The IP address of trap receiver 2
Trap receiver 3 – The IP address of trap receiver 3
Version – The SNMP version
137
software
Display information about the software.
current - For example, CXP_901_0022_R3K03.
release_time - For example, 2006-12-01 12:16.
load_timer [min] - For example, 20.
loaded - For example, CXP_901_0022_R3K03, CXP_901_0022_R3D.
permanent - For example, CXP_901_0022_R3K03.
disk - 0 or 1 (disk partition).
disks – For example, 0,1.
139
spanning_tree
Display the defined Spanning Tree (STP) parameters. 140
statistics
Display statistics information about the traffic.
connection vlan <vlan> ethernet_port <port> ingress flow
<flows> - flows is *, range or list of values.
This command returns the number of packets
and octets out that have passed policing, and
that have been discarded.
connection vlan <vlan> ethernet_port <port> egress flows
<flows> - flows is *, range or list of values.
This command returns the number of packets
and octets out that have passed policing, and
that have been discarded.
in_octets - Total bytes received.
in_pkts - Total Unicast, Multicast, Broadcast frames
received.
in_errors - FE ports: Total frames received and discarded
-
