Radio Configurations, RBS 2106 and RBS 2206
4.6.1 RBS 2106 and RBS 2206 Configurations
CDU-F Single Band Configurations
Table 23 CDU-F configurations with a fully-equipped cabinet
SCC Configuration TMA Number of
Antennas
Allowed Number of
dTRUs
1x12
F9de_2.12 No (2) (0..6)
F9det_2.12 M (2) (0..6)
F18d_2.12 No (2) (0..6)
F18dt_2.12 M (2) (0..6)
2x6 2 x F9de_2.6 No (2) (2) (0..3) (0..3)
2 x F9det_2.6 M (2) (2) (0..3) (0..3)
2 x F18d_2.6 No (2) (2) (0..3) (0..3)
2 x F18dt_2.6 M (2) (2) (0..3) (0..3)
3x4 3 x F9de_2.4 No (2) (2) (2) (0..2) (0..2) (0..2)
3 x F9det_2.4 M (2) (2) (2) (0..2) (0..2) (0..2)
3 x F18d_2.4 No (2) (2) (2) (0..2) (0..2) (0..2)
3 x F18dt_2.4 M (2) (2) (2) (0..2) (0..2) (0..2)
1x8+1x4 F9de_2.8 + F9de_2.4 No (2) (2) (0..4) (0..2)
F9det_2.8 + F9det_2.4 M (2) (2) (0..4) (0..2)
F18d_2.8 + F18d_2.4 No (2) (2) (0..4) (0..2)
F18dt_2.8 + F18dt_2.4 M (2) (2) (0..4) (0..2)
1x4+1x8 F9de_2.4 + F9de_2.8 No (2) (2) (0..2) (0..4)
F9det_2.4 + F9det_2.8 M (2) (2) (0..2) (0..4)
F18d_2.4 + F18d_2.8 No (2) (2) (0..2) (0..4)
F18dt_2.4 + F18dt_2.8 M (2) (2) (0..2) (0..4)
M = Mandatory
SCC 1 x 2 and 2 x 2 can be achieved as a subset of SCC 3 x 4 or 2 x 6.
SCC 1 x 4 can be achieved as a subset of either SCC 3 x 4 or 2 x 6.
SCC 1 x 6 can be achieved as a subset of SCC 2 x 6 or 1 x 12.
SCC 2 x 4 can be achieved as a subset of SCC 3 x 4 or 2 x 6.
SCC 3 x 2 can be achieved as a subset of SCC 3 x 4.
SCC 1 x 2 and 1 x 4 require one CDU-F.
SCC 2 x 2 and 2 x 4 require two CDU-Fs.
SCC 1 x 6 as a subset of SCC 2 x 6 requires two CDU-Fs.
SCC 1 x 6 as a subset of SCC 1 x 12 requires two CDU-Fs.
SCC 3 x 2 requires three CDU-Fs.
